LEFOO demand delivery pump is a type of diaphragm volumetric pump. The diaphragm plays a sealing and protective role in isolating the transmission medium and the power end (motor). At the same time, the regular movement of the diaphragm changes the volume of the working chamber, thereby sucking in and discharging liquid, and achieving liquid dispersion. Conveying and pressurizing. The pump head is equipped with a microswitch through the valve plate, and the microswitch and the motor end form a series connection. When the pressure increases, the valve plate deforms under the action of pressure, triggering the micro switch to cut off power; when the pressure decreases, the valve plate resumes its deformation, and the micro switch resumes power, thereby realizing automatic start and stop.
Pump
TECHNICAL PARAMETER
LEFOO LFP0150T 12VDC Demand Delivery Pump | ||||||
Model | LFP0150T-30030 | LFP0150T-30040 | LFP0150T-30045 | LFP0150T-30050 | LFP0150T-30060 | LFP0150T-30070 |
Voltage | 12VDC | |||||
Inlet Pressure | 0PSI | |||||
Working Flow | 1.50GPM | |||||
Working Current | ≤4.6A | |||||
Deliver Height | ≥2m | |||||
Break Pressure | 30PSI | 40PSI | 45PSI | 50PSI | 60PSI | 70PSI |
Maximum Current | ≤6.0A | ≤6.6A | ≤6.8A | ≤7.1A | ≤7.7A | ≤8.4A |
Optional Connections | 3/8"NPT 3/8"Side Female Quick Connector |
Automatic start and stop: high-voltage power outage and low-voltage start-up are possible;
Multiple pressure disconnect points: adjustable pressure range is 30-100PSI;
High self-priming capacity: self-priming height ≥ 2 meters, the suction chamber and discharge chamber are three-chamber independent structures, with high stability;
High-performance motor: all-copper motor, strong power, low temperature rise, and can work continuously;
Low electromagnetic noise and vibration: The motor adopts an integrated magnetization process, which has lower electromagnetic noise and vibration;
Smooth water flow: The water outlet adopts a buffer structure design, which has lower water flow pulse and vibration;
Anti-return function: anti-return structural design to prevent medium backflow;
Overheating protection: Equipped with a thermal protector, if the pump shell temperature is higher than 77°C, it can automatically stop working;
Integrated backflow pressure relief device: bypasses backflow to reduce frequent starts and stops of the pressure switch;
High waterproof performance: full range IPX5;
High stability: stable output and disconnection pressure, long life;
High strength: pressure-bearing parts are reinforced nylon and aluminum alloy;
Process-based: Full inspection and control of electrical, sealing, pressurizing and other performance production processes;
Authoritative certification: ROSH, CE, CQC, REACH certification;
RV water supply
Water supply for ships and yachts
Solar water pump system
Faucet end pressurization
Automatic filling equipment
Liquid vending machine
Equipment water circulation cooling
Purified water and drinking water
Agricultural spray system
High pressure cleaning system
Food & Beverage
Water Purification & Drinking
Cleaning robot
Carpet washer
Washing machine
Solar pumping system
Catering truck
Agricultural power sprayer pump
Agricultural water pump machine
ATV sprayer
Medical equipment
Accumulator Pressure Boost System
Mobile Booster Pump
Portable Washdown Pump
Portable washdown system
Washdown system
Welding circulating water tank
