Lefoo Peristaltic Pump with Speed Control and Display LFPC302ST

Name: Peristaltic Pump with Speed Control and Display LFPC302ST
Brand: LEFOO INDUSTRIAL CO.,LTD.
Rating: 4.8 (50 reviews)

LEFOO Stepper Motor LFPC302ST Peristaltic Pump is can control the flow rate, integrates flow statistics, timing and quantitative control, and is equipped with an LED digital speed display screen for easy operation. The speed control peristaltic pump with digital display adopts high-quality stepping motors for precise speed regulation and measurement. The digital peristaltic pump supports multi-caliber hoses and is widely used in food and beverage, environmental protection, scientific research and other industries. The speed control peristaltic pump has automatic, scheduled, and continuous modes, including back-suction and drip prevention functions, and supports external control. The button operation is intuitive to achieve all-round flow rate control.

Features

*Flow statistics function, timing/quantity control

*LED digital display speed, simple operation

*Quality stepper motor, precise speed regulation

*Accurate metering and delivery, various hose diameters

Get a Quote

Pump

Transmitter

Specification
Features
Applications

Specification of Peristaltic Pump with Speed Control and Display LFPC302/ST

Main Functions

1. Settings: Pump tube model selection, pump operating speed adjustment, screen brightness adjustment.

2. Calibration: Perform flow calibration for different media.

3. Speed Control, Fixed Volume, Timed Fixed Volume, Timed Operation.

Technical parameter

LEFOO Peristaltic Pump with Speed Control and Display LFPC302/ST
Drive mode	Stepper motor
Operating Ambient Temperature	0℃~50℃
Rated Voltage	DC24V
Operating Flow Rate	0~500ml/min(The flow rate varies with different configurations; refer to the flow selection chart for details).
Flow Accuracy	±2%
Outlet Pressure	≤0.1MPa
Suction Lift	≤8m (The flow rate decreases as the suction lift increases.)
Head	≤8m (The flow rate decreases as the head increases)
Operating Current	≤0.5A at 24V voltage
Surface Temperature Rise	≤35K at 24V voltage.
Noise	Noise requirement: ≤65dB.

Flow standard(ml/min)

Driving Mode	Control Mode	Fitting Hose	Reference Flow Rate	Operating Voltage	Power Consumption	Outlet Pressure
42 Stepper Motor	Driver + Control Board	16#	≤180ml/min	DC24V	≤20W	≤0.15MPa
		25#	≤320ml/min
		17#	≤500ml/min

Button function:

"Forward and reverse" button: set the pump running direction, display forward or reverse at the top of the screen, indicating forward/counterclockwise operation.

"Mode" button: switch screen pages (setting, calibration, speed regulation, quantitative, timing quantitative, timing timing).

"Select" button: select the parameter you need to modify.

"Start and stop" button: control the pump to run and stop (stop/start is displayed in the upper right corner of the screen).

"Knob" button: rotate the knob to adjust the parameter value; press the knob to control the pump to run and stop.

Features of Peristaltic Pump with Speed Control and Display LFPC302ST

1. Flow statistics function, timing/quantity control.

2. LED digital display speed, simple operation.

3. Quality stepper motor, precise speed regulation.

4. Accurate metering and delivery, various hose diameters.

Digital display screen: speed/flow/time/set number of cycles/gear display.

Automatic mode: automatic quantitative, automatic timing, automatic angle discharge.

Back-suction function: prevent hanging liquid, dripping, ensure accurate flow.

Support external control: support foot switch control.

Appointment mode: appointment timing quantitative angle discharge.

Continuous mode: realize continuous operation of the pump, running time, flow rate, flow discharge direction, motor speed, motor rotation direction screen real-time display.
